Contact FormDPDT

Contact MaterialGold Clad Silver Alloy

Control Voltage120 VAC

Current Rating4 A

FunctionMulti-Function

Maximum Operating Temperature65 C

Minimum Operating Temperature-40 C

Mounting TypeSocketable

Number of Pins8 Pin

Power Rating1 kVA

Primary TypeTime Delay Relays

Product DescriptionUpon the application of input voltage the relay immediately energizes. The timing cycle begins when input voltage is removed. When the timing cycle is complete, the relay will de-energize. The relay contacts will reset when input voltage is reapplied.

Product HeaderDOD Series Time Delay Relays

Relay TypeSolid State

Repeatability±5%

SeriesDOD Series

StandardsUL, CSA

Termination8-Pin Octal

Timing Range0.6 Sec. to 60 Sec.

Voltage Rating250/48 VAC/VDC
